The super short Vudu® 3-9x32 riflescope is crafted from aircraft-grade aluminum for lightweight durability. Measuring just 6.8", it is fog, water, and shock resistant, with capped ¼ MOA turrets and a second focal plane design. An illuminated reticle with 10 brightness settings runs up to 300 hours on a CR2032 battery. Its integrated base is compatible with mini-ACOG mounts. For added versatility, a version with a ring mount and EFLX™ sight allows non-magnified targeting, mountable at the top or 45-degree angles for dynamic use.

• Vudu® 3-9x32 SFP Riflescope
• Operator Manual
• Reticle Manual
• Lens Cleaning Cloth
• Battery

6.8" (172.7mm)

1.56" (39.7 mm)

16 oz (454 g)

3-9x

Yes, HC1

32 mm

CR2032

3X: 2.5-3.1" (64-81 mm)

9X: 2.3-3.1" (59-79 mm)

3X: 38 ft (11.6 m)

9X: 12.7 ft (3.9 m)

Made in Japan

Vudu HC1 Reticle

The HC1 is a second focal plane MOA- based hashmark reticle that was designed for the precision long-range shooter. The non-illuminated crosshairs allow for elevation and windage correction, while the ultra-small center aiming dot (0.15 MOA at 32X) provides the utmost accuracy. The HC1 is an excellent choice for precision long-range shooting such as bench rest, F-class and small game dog hunting.

RETICLE SPECIFICATIONS  (MOA)	HC1
ADJUSTMENT GRADUATION PER CLICK	0.25
ADJUSTMENT GRADUATION PER ROTATION	30
TOTAL ELEVATION TRAVEL	90
TOTAL WINDAGE TRAVEL	60

RETICLE DIMENSIONS  (MOA)	3x	9x
CENTER DOT DIAMETER	3.60	1.20
LINE THICKNESS	1.20	0.40
SPACE BETWEEN HASH MARKS	6.00	2.00
LENGTH OF SHORT HASH MARKS	7.50	2.50
LENGTH OF LONG HASH MARKS	15.00	5.00
